2N4124 TO-92 Small Signal Transistor NPN Darl Amp
NPN General Purpose Amplifier. This device is designed as a general purpose amplifier and switch. The useful dynamic range extends to 100 mA as a switch and to 100 MHz as an amplifier.
- Dimensions (mm): 5.21 x 5.33 x 4.19 (max)
- Lead spacing (mm): 1.27 individual (max)
- Lead Length (mm): 12.70 (min)
- Polarity: NPN
- MAXIMUM RATINGS: (TA=25°C unless otherwise noted)
- C-B Voltage VCBO: 30V
- C-E Voltage VCEO: 25V
- E-B Voltage VEBO: 5.0V
- Collector Current IC: 200 mA
- Power Dissipation PD: 625 mW
