2N5088 TO-92 Bipolar General Purpose 50ma 50V NPN
NPN General Purpose Amplifier. This device is designed for low noise, high gain, general purpose amplifier applications at collector currents from 1μA to 50 mA.
- Dimensions (mm): 5.20 x 5.33 x 4.19 (max)
- Lead spacing (mm): 1.39 individual (max)
- Lead Length (mm): 12.70 (min)
- Polarity: NPN
- C−E Voltage VCEO: 30Vdc
- C−B Voltage VCBO: 30Vdc
- E−B Voltage VEBO: 4.5Vdc
- Collector Current: 100mAdc
- Device Dissipation: 625mW
- Operating and Storage Junction Temperature Range
- TJ, Tstg: −55 to +150 °C
