Jensen C12K 100W 12" Replacement Speaker 8 Ohm
A real workhorse, heavy on the mids with a solid, straightforward tone. When presented with overdrive distortion it powers through with lows that are bold and heavy.
- Overall Diameter: 12 in
- Voice Coil Diameter: 2 in
- Magnet Weight: 50 oz
- Overall Weight: 9.48 lbs
- Flux Density: 1.10 T
Thiele-Small Parameters
- Voice Coil DC Resistance: 6.53 Ω
- Resonance Frequency: 106.2 Hz
- Mechanical Q Factor: 12.57
- Electrical Q Factor: 0.67
- Total Q Factor: 0.67
- Mechanical Moving Mass: 31.9 g
- Mechanical Compliance: 71 µm/N
- Force Factor: 14 Wb/m
- Acoustic Volume: 24.1 lt.
- Linear Displacement: 1.0 mm
- Reference Efficiency: 4.43 %
- Diaphragm Area: 490.9 cm2
- Electrical Resistance: 210 Ω
- Voice Coil @ 1kHz: 0.84 mH
Constructive Characteristics
- Magnet: Ferrite
- Voice Coil Winding: Copper
- Voice Coil Former: Kapton
- Cone: Paper
- Surround: Integrated Paper
- Dust Dome: Non-treated Cloth
- Basket: Pressed Sheet Steel
Electrical Characteristics
- Nominal Impedance: 8 Ω
- Rated Power: 100 W
- Musical Power: 200 W
- Sensitivity@1W,1m: 99.0 dB
