Un-Assembled Strat HSS 5-Way Wiring Kit

1 Review
$60.00
SKU: Z4S5W131
Weight: 0.33 lb

Temporarily Out of Stock

2115020-kit

This is a 5-way super switch kit for HSS Fender Lone Star style Strats. The super switch allows the humbucker to be coil tapped with the middle pickup. 500k pots allow the humbucker to sound full and bright and we use a resistor on the single coils to give them a normal 250k load. Use push on knobs only.
Included:
  • (3) CTS 500k vintage taper audio split shaft 7% tolerance potentiometers
  • (1) Oak Grigsby 5-way 4 pole super switch
  • (1) Switchcraft mono input jack
  • (2) Vitamin T Oil Filled .022uf capacitor
  • (2 ft) Pre-tinned cloth covered black wire
  • (2 ft) Pre-tinned cloth covered white wire
  • (1) 470k carbon comp resistor

Ratings & Reviews

1 review

  • 4 stars
  • 0 reviews
  • 3 stars
  • 0 reviews
  • 2 stars
  • 0 reviews
  • 1 star
  • 0 reviews
6/16/2021 11:48 pm

Great kit

by Nate -

This is a great kit that has all the parts needed. Used it to upgrade my Strat to split the bridge humbucker in the second switch position. No wiring diagram included, but mojotone has diagrams on the website that helped me troubleshoot.
